Anläßlich des CCD-Praktikums der Fachgruppe CCD der VdS (15.-17. Oktober 2004) haben wir uns mit mehreren Amateurastronomen am 12. Oktober an der VdS-Sternwarte Kirchheim getroffen. Neben diversen Kometenaufnahmen, die Berd Brinkmann und Konrad Horn gelungen sind, haben sich Gerd Neumann und ich mit dem Coronado H-Alpha-Filter (50mm Öffnung) der Sternwarte auf die Jagd nach Sonnendetails gemacht.
|
From October 15 to October 17
the CCD section of the VdS met for a ccd workshop at the VdS
observatory in Kirchheim near Erfurt. A few of us met on October
12 and apart from comet images taken by Bernd Brinkmann and Konrad
Horn, Gerd Neumann and myself took some images with the Coronado
H-Alpha filter. The weather started to change on wednesday (Oct.13) and we had to take the images through thin clouds. The following images still show some detail. The images were taken with a Mintron video camera and a 2x barlow lens. With that setup the focal length was about 2.4m. |
13.
Oktober 20043 |
|||
13:31 UT |
11:34 UT
|
11:36 UT |
11:41 UT
|
11:53 UT |
12:09 UT |
Durch einen Fehler beim Erstellen der Videofiles fehlt leider am 14. Oktober die Uhrzeit. Die Aufnahmen sind aber alle im Laufe des frühen Nachmittags entstanden. | Due to an error while creating
the video files the timestamp for the images on Oct. 14 is missing. The
images were taken during the early afternoon. |
14.
Oktober 2004 |
|||
15. Oktober 2004 |
|||
13:38 UT
|
15:15 UT |
15:19 UT |
Die Aufnahmen wurden
mit Giotto 1.42 bearbeitet.. Anschließend wurde der Kontrast mit
Photo Paint angepaßt. Da sich einige Details über die Tage weiter verfolgen ließen, sind die folgenden Vergleichsbilder zusammengesetzt worden: |
The images have been processed
with Giotto 1.42. Then contrast and brightness have been adjusted with
Photo Paint. As some of the detail was visible on more than just one day the following images have been created for easy comparison: |
Technische Daten: Telescope: Refraktor 80mm Öffnung, 1.2m
Brennweite |
Technical data: Telescope: Refractor 80mm aperture, 1.2m focal
length |
